ITPC-A121 Touch Screen panel pc
◆ 12.1inch All-in-one Touch panel pc
◆ Intel Celeron J1900 quad core
◆ Adopt HD Industrial Screen, Brightness : 450 cd/m2
◆ Taiwan’s Resistance 5 wire Touch Screen
◆ 1*mini-PCIE(support Wifi/BT/3G/4G),1*mini-PCIE(support MSATA)
◆ Support1*VGA, 1*HD, 1*LVDS；
◆ Support Desktop、Embedded、Wall Mount、VESA.
 |  |
| System Parameter | |
| Model | ITPC-A121 Touch Screen panel pc |
| Processor | Intel Baytrail quad core J1900 |
| Chip | Intel CPU Integrated Chip |
| Memory | 1* SODIMM DDR3L 1333/1600, MAX: 8GB |
| BIOS | 64Mb Flash ROM |
| Display Chip | Intel HD Graphics 2500 |
| Display port | 1*VGA，1*HDMI，1*LVDS【Support synchronous or asynchronous dual display】 |
| Storage | Support 1*MSATA，1*2.5 inchs SATA |
| I/O | 1*USB3.0，3*USB2.0，2*RS232【6*COM is optional（COM3 support RS232/422/485）】，1*VGA，1*HDMI，1*1000M RTL8111E【2 is optional】，1* DC-IN1*3Pin Power connector，1*Mic，1*Line Out |
| Expansion Slot | Support 1*MSATA Slot |
| Support 1*Mini PCIE Slot【WIFI/Bluetooth/3G/4G Optional，1*SIM Slot】 | |
| Network | 1*1000M RTL8111E【2 is optional】 |
| LCD | Size：12.1 inchs TFT-LCD； |
| Ratio：4：3； | |
| Resolution：1024 * 768； | |
| Brightness：450 cd/m2； | |
| Viewing Angle：Full Angle | |
| Touch Screen | Resistance Touch Screen(Single Touch)，Life Time > 50 million |
| Speaker | 2* 8W speaker |
| Power Supply | DC 12V【DC 9～36V is optional】 |
| Certificates | CE、 CCC、 FCC Class A、 ROHS |
| Application | Industrial Automation, Medical, Logistics Transportation, Warehouse, Electronic Education etc. |
| Structure Parameter | |
| Color | Black (Color can be customized) |
| Material | Pure Aluminum |
| Size | 312 * 250 * 51 mm |
| Embedded Install | 302 * 240 mm |
| Weight | 3.3 kg |
| Environmental Parameter | |
| Work Temp | 0℃ ～ +40℃【Commercial HDD】，-10℃ ～ +50℃【Industrial SSD】，surface air flow |
| Work Humidity | 5% ～ 95% Non-condensing |
12.1 ”J1900 Quad Core All In One A121 Wall Mount Touchหน้าจอคอมพิวเตอร์
