Industrial embedded computer/industrial computer
The TBOX series of industrial embedded computers embodies the “modular” design and manufacturing concept that Tyson has insisted on. For all design factors such as the selection and layout of motherboards, components, heat sinks and cooling system design, precise structure and engineering design, to achieve the best use effect for customers. Taishengen embedded TBOX series industrial computer, including a variety of performance, size and function of fanless embedded computers, can be widely used in industrial Internet of things, industrial automation, commercial automation, smart factories, machine automation, machine vision, environment And industrial facility monitoring, building automation, intelligent manufacturing and other related industrial fields, quickly and flexibly provide customers with reliable industrial hosts and reduce risks.
At the same time, as an industrial host with a modular design and manufacturing concept, the Tyson TBOX series are equipped with Tyson TM series industrial display panels to quickly provide an industrial touch panel system and realize interactive operation of man-machine interface.
Ultra compact size (TBOX-1 Series)
TBOX-1 series is a super compact fanless industrial computer, compatible with Intel’s multiple mobile platform processors, including APOLLO LAKE platform Celeron J3455/J3355 processor, 6th and 7th generation Core i3, i5, i7 processors. The TBOX-1 series fanless industrial computer is super compact, close to the size of an adult’s palm, and super mini. In its limited space layout, it supports 2 Intel Gigabit Ethernet ports, 4 USB3.0/2.0 ports, 1 HDMI independent display port, and optionally supports 3G, 4G, Wi-Fi, Bluetooth and other wireless expansions. Support industrial module expansion such as CAN-BUS
Rich Interface Type (TBOX- 2XX0 Series)
TBOX-2XX0 series is a fanless industrial computer system widely used in various industrial fields, compatible with Intel’s processors on multiple mobile platforms, including Baytrail platform Celeron J1900/J1800 processor, Apollo lake platform competition Yang J3455/J3355 processor, 6th and 7th generation Core i3, i5, i7 dual-core processors. TBOX-2 is designed with a wealth of IO interfaces, including 2 Intel Gigabit Ethernet ports, 6 USB3.0/2.0 ports, 6 DB9 serial ports, 1 HDMI and 1 VGA independent display interface, supporting 3G/4G/LTE /Wi-Fi/Bluetooth wireless expansion and CAN-BUS/ProfiNet and other industrial expansion modules.
Rugged and Rich IOs (TBOX-2xx5 Series)
The TBOX-2xx5 are modular concept designed & manufactured industrial fanless Box PC series. It delivers rich IO interfaces, includes 2 GbE, 6 USB, 6 COM, 2 HDMI ports; The TBOX-2xx5 provides optional 3G/4G, Wi-Fi/BT, 5G/Wi-Fi6 via its internal 2 M.2 Key slots.
The rugged Box computer TBOX-2xx5 can be equipped with Intel Apollo Lake J3455, Intel 8th Gen. Whiskey Lake Celeron, Core i3/i5/i7, Intel Elkhart Lake J6412, and Intel 11th Gen. Tiger Lake UP3 Celeron, Core i3/i5/i7 processors. The TBOX-2xx5 support TPM2.0 and Windows 11 OS platform, industrial wide operating temp. -20 to +70 degree range, very suitable for various of industrial & embedded projects.
POE Function Type (TBOX- 3 Series)
TBOX-3 series is a multi-network port fanless industrial computer, compatible with Intel’s high-performance Core i3, i5, i7 dual-core processors. TBOX-2 is designed with a wealth of interfaces, including 5 Intel Gigabit Ethernet ports (supports 4 PoE functions), 6 USB interfaces (4 camera interfaces), 2 RS232 serial ports, 1 HDMI and 1 VGA display interface, 32-channel GPIO function (16-channel digital input and output), also supports 3G/4G/LTE/Wi-Fi/Bluetooth wireless expansion and CAN-BUS industrial function module. The TBOX-3 series is very suitable for industrial applications such as machine vision and industrial networks.
Low power & Ultra slim industrial box computer
(ABOX- E5)
ABOX-E5 series is ABOX-E5 deploys 4th Intel Baytrail low power J1900 CPU processor, which is back-mounted on mainboard to make it closer to the metal housing for better cooling. The widespread aluminum fins designed heat sink also guarantees better heatdissipation, thus longer system lifespan. ABOX-E5 is also integrated with wide range power input with over-voltage,over-currentand plarity protection. The housing simulates diamond-cutting design, which makes it more solid and slimdesign.
ABOX-E5 is equipped with 2 Intel Gigabit Ethernet ports, 5 USB ports, 2 COM ports, 1 HDMI, 1 VGA and DC jack ports.
TBOX-4xx0 Series | Power-efficient & Expandable | Multiple Expansion Box PC
TBOX-4TXX series TAICENN TBOX-4TXX Modular Box PC is Powered by the Intel 11th Gen. Tiger Lake UP3 Core i3-1115G4 Dual-core processor, Intel Tiger Lake UP3 Core i5-1135G7 , Intel Tiger Lake UP3 Core i7-1165G7, which have super high cost-performance for industrial automation applications. Its advanced industrial design includes a DC terminal with a wide DC 9~36V range power input. The TBOX-4T11 industrial Box PC is designed with rich I/O interfaces that includes 2x USB 3.1 & 2x USB 3.0 ports, 1x USB-C (USB3.1 & DP1.4a), 2x DB9 RS232/RS485/RS422(BIOS configured), 1x SW Remote Switch, 2x HDMI, 2x GbE LAN ports, Audio port, optional 1x GPIO (8-ch). This fanless PC provides 3 high speed expansion slots (1* M.2 3042/3052 B-Key, 1* M.2 2242 E-Key, 1* Mini-PCIe),can optional support 3G/4G, 5G, Wi-Fi6, Wi-Fi/BT wireless functions. Also, TPC-DCT/DRT T series provides more powerful expansion possibilities, and offer flexible and fast expansions for industrial field applications to improve product performance.
The TBOX-4T11 also support TPM2.0, can be compatible with Windows10, Windows11, Linux Operating system and embedded Operating system.
